Timber 29 Carbon

On Sale!

Price range: $3,349.00 through $5,349.00

Our Timber 29 Carbon is a super lightweight 29 inch hardtail mountain bike built for ambitious youth riders and adults who want real trail performance. With 110mm of efficient, race ready front end travel and a superlight carbon frame, it climbs fast, accelerates hard and descends with confidence. Premium RockShox SID Ultimate suspension with a remote lockout allows push button lockout capability.

Model

Elite
GX AXS
Pro
XX AXS

Color

Frame Size

Large
Medium
Small

Clear

Additional Options

- +

SKU: N/A Category: Bikes Tag: 29 Inch Bikes

Description

The All New Timber 29 Carbon

When our own kids grew out of our brand and had to start their high school racing programs on other bike brands, we knew we had to keep the Trailcraft line going. Big 29” wheels. SUPERLIGHT high modulus carbon frame. Maximum lateral stiffness but vertically compliant. All of the speed. Everything you know and loved growing up riding with our smaller bike line finally extends into the 29” wheel size!

Aspirations of racing you say? No problem. This is a true lightweight 29 inch hardtail racer built to fly! Internal cable routing keeps everything super clean. Our new Timber 29 Carbon even has a Universal Derailleur Hanger (UDH) so if you even needed a derailleur hanger fast, most good local bike shops now carry them.

We Offer 4 Build Levels for the Timber 29 Carbon:

PRO Level Build - $3,349
This bike gets the Deore 11 speed workhorse drivetrain to keep cost as low as possible, but still has that sweet 11-51 cassette range for climbing.

ELITE Level Build - $3,849

An XT M8100 bike with full XT M8100 brakes, 10-51 cassette, XT 8100 rear Derailleur and XT I-spec II shifter!

GX AXS Electronic Shifting Build - $4,599

The Full GX AXS drivetrain package. A high-performance setup built to handle everything from big climbs to aggressive descents.

XX Superlight AXS Electronic Shifting Build - $5,349

The SUPERLIGHT XX represents the best of everything — featuring SRAM’s Superlight Eagle AXS T-Type rear derailleur for next-level wireless performance.

Looking for something truly one-of-a-kind? We offer fully custom builds. Contact us for current market pricing and let’s build your dream bike.

These are our launch edition builds. We are also developing more affordable options featuring non Superlight SID Ultimate forks to help bring entry pricing down while keeping the Maxwell 29 performance DNA intact.

All bikes are assembled in Fort Collins, Colorado. Want to tweak a build or personalize your setup? No problem. Let us build your dream 29er 120mm trail bike!

Frequently Asked Questions

Will my child or I fit the Timber 29 Carbon?

The Timber 29 Carbon fits riders in three size categories:

Small (S): approximately 5'2" to 5'6" (about 157–168 cm) tall.

Medium (M): approximately 5'6" to 5'11" (about 168–180 cm) tall.

Large (L): approximately 5'11" to 6'2" (about 180–188 cm) tall.

What is the weight for the Timber 29 Carbon?

The Timber 29 Carbon starts at 22.5 lbs. Different part customizations may change the estimated weight. Check out our specs to learn more.

Features

Ultralight carbon frame
Best-in-class stiffness to weight ratios
Lightweight integrated headset
New-school hardtail racing geometry
Internal routing for the cleanest system
UDH rear derailleur hanger – All Bike Shops Stock Them Now

Specs

MODEL	Pro Build	Elite Build	GX AXS Build	XX AXS Build
FRAME	Timber 29 Carbon	Timber 29 Carbon	Timber 29 Carbon	Timber 29 Carbon
FORK	Rock Shox SID Ultimate SL 110mm w remote Lockout	Rock Shox SID Ultimate SL 110mm w remote Lockout	Rock Shox SID Ultimate SL 110mm w remote Lockout	Rock Shox SID Ultimate SL 110mm w remote Lockout
HEADSET	Trailcraft Precision Sealed Cartridge	Trailcraft Precision Sealed Cartridge	Trailcraft Precision Sealed Cartridge	Trailcraft Precision Sealed Cartridge
SHIFTER	Shimano Deore 11 Speed	Shimano XT 8100 12 Speed	Sram EC AXS Pod Wireless	Sram EC AXS Pod Wireless
DERAILLUER	Shimano Deore 11 Speed	Shimano XT 8100 12 Speed	Sram GX AXS T-Type Wireless	Sram RD XX SL Eagle AXS T-Type Wireless
BRAKES	Shimano Deore M6100 Hydraulic	Shimano XT M8100 Hydraulic
CRANKS	Trailcraft Direct Mount, 32 tooth Chainring	Trailcraft Direct Mount, 32 tooth Chainring	SRAM GX AXS T-Type 32 tooth chainring	SRAM XX SL AXS 32 tooth chainring
BAR	Trailcraft Alloy Riser	Trailcraft Carbon Riser	Trailcraft Carbon Riser	Trailcraft Carbon Riser
GRIPS	SRAM Twitico Ultimate (dual lockout)	SRAM Twitico Ultimate (dual lockout)	SRAM Twitico Ultimate	SRAM Twitico Ultimate
STEM	Trailcraft, Length: 50mm	Trailcraft Superlight Length: 50mm	Trailcraft, Length: 50mm	Trailcraft Superlight Length: 50mm
POST	KS Lev SI 31.6	KS Lev SI 31.6	KS Lev SI 31.6	KS Lev SI 31.6
SADDLE	Trailcraft	Trailcraft	Trailcraft	Trailcraft
PEDALS	VP Composite with metal pins	VP Composite with metal pins	VP Composite with metal pins	VP Composite with metal pins
CASSETTE	Shimano Deore 10-51 11 Speed	Shimano XT 8100 10-51 12 Speed	Sram GX 10-52 12 speed	Sram XX CS XS T-Type 10-52
WHEELSET	Trailcraft Aluminum (Carbon Upgrade Option)	Trailcraft Aluminum (Carbon Upgrade Option)	Trailcraft Aluminum (Carbon Upgrade Option)	Trailcraft Aluminum (Carbon Upgrade Option)
TIRES	Maxxis Rekon Race 2.35" - set up tubeless with Orange Seal	Maxxis Rekon Race 2.35" - set up tubeless with Orange Seal	Maxxis Rekon Race 2.35" - set up tubeless with Orange Seal	Maxxis Rekon Race 2.35" - set up tubeless with Orange Seal
MSRP	$3,349	$3,849	$4,599	$5,349

Model	Elite, GX AXS, Pro, XX AXS
Color	Black, Turquoise
Frame Size	Large, Medium, Small

Reviews

There are no reviews yet.

Be the first to review “Timber 29 Carbon”

You must be logged in to post a review.

Geometry

Size	TTL	STL	STA	HTL	HTA	RC	BBH	Fork Length	Offset	Reach	Stack	FC	WB
Small	582.9	410	75 degrees	87mm	67,8 degrees	425mm	38mm	505mm	44mm	420mm	598mm	683mm	1100mm
Medium	607	440	75 degrees	93.5mm	67.8 degrees	425mm	38mm	505mm	44mm	445mm	604mm	708mm	1125mm
Large	630	480	75 degrees	106mm	67.8 degrees	425mm	38mm	505mm	44mm	465mm	616mm	732mm	1150mm

Size Chart

SMALL	MEDIUM	LARGE
5'2" - 5'6"	5'6" - 5'11"	5'11" - 6'2"

If you find yourseld between sizes, the ideal approach is to examine the current reach and stack measurement of your current bike.

Not everyone with the same height has the same body shape! If you’ve got longer legs and shorter torso (compared to the average person of your height) you might want to consider going with a smaller size. If you have a longer torso and longer arms, you might be better off sizing up!
