Maxwell 26 LTD

On Sale!

Original price was: $2,499.00.Current price is: $2,299.00.

The Maxwell 26 LTD is a lightweight 26 inch mountain bike with trail-tuned suspension and agile geometry for smaller riders. Weighing in at just 28 pounds, lighter than others in its category, we are confident this bike will help your young rider dial in their skills and push their limits on the trail.

Additional Options

Add KS Lev SI Dropper Post

100mm dropper post upgrade!

SUPERBEAST It With a PIKE 130 – Rock Shox PIKE 130mm Fork Upgrade!

Ride some days at the park but also want an all-arounder type of bike for big trail/enduro style rides where you still need a bike to climb well? Click the 130mm travel PIKE UPGRADE checkbox to get a super sweet heady duty trail bike setup!

SUPERPINK bling kit! Upgrade to sweet PINK anodized cranks/chainring, tubeless valves, grip ends and pedals!

REALLY like pink? Love your bike even more and take your build to the next level with our SUPERPINK upgrade kit.

SUPERGREEN bling kit! Upgrade to sweet GREEN anodized cranks/chainring, tubeless valves, grip ends and pedals!

REALLY like green? Love your bike even more and take your build to the next level with our SUPERGREEN upgrade kit.

SUPERBLUE bling kit! Upgrade to sweet BLUE anodized cranks/chainring, tubeless valves, grip ends and pedals!

REALLY like BLUE? Love your bike even more and take your build to the next level with our SUPERBLUE upgrade kit.

Maxxis Ikon 26×2.2″ tire option (better for fast XC riding) – no extra charge
FREE TUBELESS TIRE SETUP this month – A $40.00 Value!

Have us set your bike up with our PREMIUM tubeless valves and Orange Seal Endurance Sealant! The best low-cost performance upgrade you can do…and we are doing it for FREE this month!

Trailcraft Carbon Riser Bar

Maximum awesomeness!

- +
SKU: MX26-023A-LTD Category: Tag:

Description

On Sale This Month! Order Today!

We've engineered this bike for trail dominance! This exceptional machine boasts a Microshift 10-speed drivetrain complete with a super wide-range Microshift 11-48 cassette, TEKTRO Hydraulic Disc brakes, and a 30-tooth chainring. Remarkably, it weighs in at a mere 28 pounds, surpassing others in its category, many of which weigh 33 pounds or more. We've been able to take the price down even lower thanks to our Trailcraft wheels now back in stock.

These bikes come standard with a 30-tooth chainring and an 11-48 cassette for convenient ordering. However, we can accommodate adjustments for those living in particularly steep areas (26 or 28 tooth chainrings may be preferable) or flatter regions (32 tooth chainring option available) - just let us know what you prefer in the comments/order notes during the checkout process.

Please refer to the spec sheet for component specifications rather than relying on the actual picture for details as our builds might change during availability.

Frequently Asked Questions

Will my child fit the Maxwell 26 LTD?

The Maxwell 26 LTD is designed for riders around 4'7" to 5'2" (about 140–157 cm) and an inseam around 27.5 inches (70 cm).

How heavy is the Maxwell 26 LTD?

The LTD version of our Maxwell 26 weighs in at a mere 28 pounds, surpassing many others in its category.

What's the difference between the Maxwell 26 LTD and the Maxwell 26?

The Maxwell 26 LTD is our ready-to-ride build, meaning it comes fully assembled with curated specs. Our Maxwell 26 is built to order, meaning you can customize components, chainring size, and more to dial the bike in exactly for your rider and terrain. Looking for more custom configuration options? Check out our customizable Maxwell 26.

Specs

MODELMaxwell 26 LTD
FRAMEMaxwell 26 7005 Series Aluminum
REAR SHOCKRock Shox Monarch RT - 120mm travel
FORKRock Shox Recon (w/ 2026 Debonair cartridge) 130mm - Boost
HEADSETTrailcraft Precision Sealed Cartridge
REAR DERAILLEURMicroshift Advent 10 Speed
FRONT DERAILLEURN/A
SHIFTERMicroshift Advent 10 Speed
BRAKESTektro Hydraulic (short reach lever!)
CRANKSTrailcraft Direct Mount, Alloy Spindle, 152mm length with 30 tooth Chainring
BARTrailcraft Alloy Riser
GRIPSTrailcraft Lock-On
STEMTrailcraft, Length: 50mm
SEATPOSTTrailcraft Rigid, 30.9
SADDLETrailcraft
CASSETTEMicroshift 11-48 Cassette
WHEELSETTrailcraft Alloy rims, Boost hubs 12x148
TIRESKenda Regolith 2.2”
Set up Tubeless
MSRP$2499.00
Estimated Weight28 pounds
Color

Neon Green, Red, Black, Orange, Turquoise

2 reviews for Maxwell 26 LTD

  1. Rated 5 out of 5

    Mary Bengtson (verified owner)

    We bought a bike for my 10 year old a few months ago. He is notorious for breaking gear which is why we did not leave a review right away. So far this bike has held up really well and we have been really impressed. He is small for his age, however this bike is light enough he can still maneuver it easily.

    Thank you for making an awesome bike!

  2. Rated 5 out of 5

    susanne veereschild

    These bikes are beautiful and very well made. Our 9 and 10 year (27.5 LTD) old each have one and they love them! Perfect for the mountains of North Carolina! Delivery is fast!

Add a review

Geometry

Geometry - Maxwell 26(millimeters)
Seat Tube Length-Center to Top380
Top Tube Length(Horizontal)550
Top Tube Length(Actual)520
Chainstay Length420
Bottom Bracket Height (approx)320
Seat Tube Angle(Actual)74 Degrees
Head Tube Angle (120mm travel fork..140mm puts it at 65 degrees)66 Degrees
Wheel Base1082
Standover Height675
Reach389.6
Stack559.4

Size Chart

Approximate Age10-13
Minimum Inseam27 inches
Height Range4'10"-5'2"
